MS-TECH Turbo G-Series Ball Bearing Racing G25-550 G25-660 Turbocharger 871389-0004 for Universal Racing Car

Model G25-660
Part No. 871389-0004
Compressor details a/r 0.70 anti-surge
air inlet 3" air outlet 2"
inducer 54.34mm exducer 67.40mm
Compressor Trim: 65
Turbine details a/r .72
Turbine Housing Inlet: 3 Inch O.D. V-Band
Turbine Housing Outlet: 3.55 inch (90mm)O.D. w/81mm centering ring V-Band
inducer 53.85mm exducer 49.36mm
Turbine Trim: 84
Car Application for G-Series G25-660
for G25-660(A/R.72)
Availability:
Quantity:
  • G25-550/660

  • MS-TECH Turbo

  • 871388-5001S

  • other

  • other

  • other

  • other

  • other

  • other

  • other

  • racing car

  • other

  • racing car

  • other

  • 6 months

  • other

  • other

  • 550-660 hp

  • Regulated Type

  • Normal Temperature

  • YES

  • carton

  • China

  • 50*50*50

  • other

  • MS-TECH

  • Other

  • Other

Model

G25-660

Part No.

871389-0004

Compressor details

a/r 0.70 anti-surge
air inlet 3" air outlet 2"
inducer 54.34mm exducer 67.40mm
Compressor Trim: 65

Turbine details

a/r .72
Turbine Housing Inlet: 3 Inch O.D. V-Band
Turbine Housing Outlet: 3.55 inch (90mm)O.D. w/81mm centering ring V-Band
inducer 53.85mm exducer 49.36mm
Turbine Trim: 84

Car Application

for G-Series G25-660
for G25-660(A/R.72)



IMG_20240201_104010IMG_20240201_104042

IMG_20240201_103820IMG_20240201_104401
